ABB 3BSE050090R20设备网扫描器模块

频率输入模件

2通道

RS422.5V. 12V .24V .13MA变送器接口

脉冲计数和频率测量

频率模件接收过程频率与脉冲输入信号:

29位计数器双向脉冲计数(宽度/位置)累积

频率测量范囤025Hz-1.5MHz

技术数据

供电电压: 24Vdc(12-32Vdc)

输入耐压: 30Vdc

信号电缆长度: 200m

电缆类型.阻抗:屏蔽双绞1002(+/-25%)

输入滤波: A/B输入无/1us,

ST输入1us/1 ms, DI输入1ms/5ms

DO输出最大负载: 0.5A

DO输出最大短路电流: 2.4A

DO输出漏流10uA

DO输出阻抗0.40

DP820电流损耗+5V: 120mA

功耗: 2.5W

输出预置时间: 256. 512. 1024ms

电压监视: 2通道

隔离:通道隔离50V

防误插代码CB
